Sinotruk howo heavy duty Mineral dump truck 6x4 Mining truck for sale

  • 1 - 4 Sets
    US $85000.00
  • 5 - 9 Sets
    US $83000.00
  • >=10 Sets
    US $78000.00
Model Number:
OEM OEM
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
HOWO
Product name:
Mining dump truck 70 ton for sale Sinotruk howo Mineral truck
Type:
Mining dump truck
name:
Mineral truck
Size:
Mining dump truck 70 ton
Material:
10 wheeler
Color:
RED WHITE BLUE YELLOW
Car Make:
sinotruck howo
OEM:
OEM Service
Application:
dump truck
Certificate:
ISO9001
SupplyAbility
SupplyAbility:
200 Set/Sets per Quarter Mining dump truck 70 ton for sale Sinotruk heavy Mineral truck
Packaging & Delivery
Packaging Details
Mining dump truck 70 ton for sale Sinotruk howo heavy duty Mineral truck 420HP
Port
QINGDAO TIANJIN SHANGHAI
Lead Time :
20 DAYS

 --_02



Body

Carriage Internal Dimensions(mm)

5800x3100x1500

Cubage (m3)

27

Steel thickness of Carriage(mm)

Floor:16mm/Side:14mm

Steel

Q345

Hydraulic Lift of Carriage

Front Lift

Weight in kg

Kerb weight (Kg)

23000

Gross vehicle weight (Kg)

75000

Dimension(mm)



Dimensions(mm)

Length(mm)

8800

Width(mm)

3400

Height(mm)

4400

Wheel base (mm)

3800+1500

Performance

Maximum driving speed (km/h)

46(10.47)

Fuel consumption  (1/100 km)

50

Cab

Model

SINOTRUK HW7D single side cab



No bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner

Engine

Model

WD615.47T2(Euro 2)

Type

6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection

Horsepower

371

Maximum output Kw/r/min

273/2200

Maximum torque N.m/r/min

1460/1300-1600

Bore x Stroke

126x130mm

Valve

2

Displacement

9.726L

Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan

Transmission

SINOTRUK HW21712 transmission ,12 forward and 2 reverse with HW70 power takeoff

Clutch

SINOTRUK CH430-21-model diaphragm-spring clutch,hydraulically operating with air assistance

Steering

ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)

Front Axle

SINOTRUK HF12 Front Axle,HOWO 12-ton front axles of equipped with drum brakes.

Rear Axles

SINOTRUK AC26 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles,enforced STR axle,ratio:10.47

Brake System

Service brake:dual circuit compressed air brake

Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

With ABS

Wheels & Tyres

Rims:10.0-25,12 hole-steel ;Tyres:14.00-25(36PR) Mining tyre with 1 Spare tire.

Electrics

Operating voltage:24V,negative grounded

Starter:24V,7.5 Kw

Alternator:3-phase,28V,1500 W

Batteries:2x12 V,165 Ah

horn,headlamps,fog lights,brake lights,indicators and reverse light



Oil Tank

D type-500L Aluminum alloy fuel tank
